Cirrus Aircraft 70247-001 Mixture Cable Clamp Kit, SR22T — SB2X-72-01
On early SR22Ts, engine components forward of the firewall may show signs of chafing. SB2X-72-01 inspects for it and corrects it, with kits that reduce the contact areas.
Cirrus classes SB2X-72-01 as mandatory, at the next scheduled maintenance, annual inspection or within 100 flight hours, whichever occurs first. The air box seal and air/oil separator work that was originally part of this bulletin now sits in SB2X-71-17 (kit 70257-001) and SB2X-71-19 (kits 70259-001 and -002).
What the kit does: Supplies an Adel clamp and hardware that secure the mixture cable at the cabin side of the firewall.
Which kits do I need: The bulletin covers SR22T serials 0001 thru 0025 and 0027 thru 0041, and each kit covers part of that range. 70246-001, A/C compressor belt and turnbuckle — serials 0001 thru 0025 and 0036, with air conditioning. 70247-001, mixture cable clamp — serials 0001 thru 0025. 70251-001, improved crossover ducts — serials 0001 thru 0020, 0022, 0024 and 0025. Refer to SB2X-72-01 to confirm applicability before ordering.
Reference only — not a maintenance authority. The part numbers, effectivity and service bulletin references shown above are published as an aid to our customers and may not reflect current Cirrus data. They must not be used as the basis for installation. Mechanics must obtain and use their own current Cirrus Illustrated Parts Catalog and the current revision of any service bulletin, and must verify applicability against the aircraft serial number, service bulletin compliance and any installed STCs, before ordering or installing any part.
