Cirrus Aircraft 70261-105 Iridium Base Harness, Bulkhead 222 — SB2X-34-27
The Iridium base harness for installations with the transceiver at bulkhead 222 — the harness supplied in installation kit 70261-001 (SB2X-34-27, Groups A and C).
Note: For SR20 serials 2016 and subsequent, SR22 serials 2979, 2992, 3002, 3003, 3024 and subsequent, and SR22T serials 0001 and subsequent, all with Perspective avionics. Refer to SB2X-34-27 to confirm applicability before ordering.
Reference only — not a maintenance authority. The part numbers, effectivity and service bulletin references shown above are published as an aid to our customers and may not reflect current Cirrus data. They must not be used as the basis for installation. Mechanics must obtain and use their own current Cirrus Illustrated Parts Catalog and the current revision of any service bulletin, and must verify applicability against the aircraft serial number, service bulletin compliance and any installed STCs, before ordering or installing any part.
