Cirrus Aircraft 70270-001 Alternate Oil Temperature Sensor Kit — SR20, SB2X-79-03
On affected SR20s the oil temperature sensor sits in the oil cooler adapter, close to the anti-congealing oil flow. When the oil cooler is in bypass with cold oil, that position biases the reading low. Hot oil temperature readings are not affected.
Cirrus classes SB2X-79-03 as optional.
What the kit does: Supplies an alternate oil temperature sensor with its gasket and the connector parts to wire it in.
Why it works. The alternate sensor is positioned more directly in the bypass oil flow, so it measures cold oil temperature more accurately.
Note: For SR20 serials 1005 thru 2015. Refer to SB2X-79-03 to confirm applicability before ordering.
Reference only — not a maintenance authority. The part numbers, effectivity and service bulletin references shown above are published as an aid to our customers and may not reflect current Cirrus data. They must not be used as the basis for installation. Mechanics must obtain and use their own current Cirrus Illustrated Parts Catalog and the current revision of any service bulletin, and must verify applicability against the aircraft serial number, service bulletin compliance and any installed STCs, before ordering or installing any part.
