Description
Cirrus Aircraft 70096-005 Cabin Door Adjustment Bushing Kit — SR20/SR22, SB2X-52-03
SB2X-52-03 upgrades the cabin door latching assembly — rotary latches, rotary arms, handle levers, actuators and striker pins — on early SR20 and SR22 aircraft.
The bulletin is optional, at the owner's option. Many aircraft need more than one kit.
What the kit does: Supplies six adjustment bushings.
Which kits do I need: Each kit covers its own serial range — order every kit that includes the aircraft.
- 70096-001 rotary latches — SR20 1423–1424, SR22 0795 and 0820–1012
- 70096-002 cable attach brackets — SR22 0795 and 0820–0890
- 70096-003 rotary arms — SR20 1423–1439, SR22 0795 and 0820–1012
- 70096-004 striker pin spacers — SR22 0821–0838
- 70096-005 adjustment bushings — SR20 1423–1424, SR22 0795 and 0820–0976
- 70096-006 handle levers — SR20 1423–1455, SR22 0795 and 0820–1066
- 70096-007 latch actuators — SR20 1423–1424, SR22 0795 and 0820–1016
- 70096-008 striker pins — SR20 1423–1472, SR22 0795 and 0820–1154
- 70096-009 handle screws — SR20 1423–1455, SR22 0795 and 0820–1066
Refer to SB2X-52-03 to confirm applicability before ordering.
Reference only — not a maintenance authority. The part numbers, effectivity and service bulletin references shown above are published as an aid to our customers and may not reflect current Cirrus data. They must not be used as the basis for installation. Mechanics must obtain and use their own current Cirrus Illustrated Parts Catalog and the current revision of any service bulletin, and must verify applicability against the aircraft serial number, service bulletin compliance and any installed STCs, before ordering or installing any part.
